The SSW-120-01-T-D is a receptacle connector from Samtec Inc. It belongs to the SSW series and has 40 positions.

• Series: SSW
• Positions: 40
• Contact Type: Forked
• Termination: Solder
• Fastening Type: Push-Pull
• Contact Material: Phosphor Bronze
• Insulation Color: Black
• Pitch: 0.100" (2.54mm)
• Contact Finish: Tin
• Temperature Range: -55°C to 105°C
• Current Rating: 4.7A per contact
• Flammability Rating: UL94 V-0
• Insulation Material: Liquid Crystal Polymer (LCP)
• Mounting Type: Through-Hole
• Row Spacing: 0.100" (2.54mm)
• Contact Length (Post): 0.104" (2.64mm)
• Insulation Height: 0.335" (8.51mm)
• Status: Active
• Package: Bulk
