ON Semiconductor FAN3226CMPX Dual High-Speed, Low-Side Gate Driver

The FAN3226CMPX from ON Semiconductor is an advanced dual high-speed, low-side gate driver designed to drive N-channel enhancement-mode power MOSFETs and IGBTs with high efficiency and speed. This driver is an ideal choice for a wide range of applications, including switch-mode power supplies, motor controllers, and DC-DC converters, where fast switching and efficient operation are crucial.

Featuring a 4.5V to 18V wide operating voltage range, the FAN3226CMPX ensures compatibility with various control logic levels, making it flexible for use in multiple system designs. The device is capable of delivering peak output currents of up to 4A, providing the necessary drive strength for fast switching of connected power devices, which is essential for reducing switching losses and improving overall system efficiency.

The FAN3226CMPX includes two independent channels that can be configured for non-inverting or inverting operation, offering design flexibility. Each channel has its own 3A typical source and 4A sink current capability, ensuring robust drive for the power switches. The driver's matched propagation delay between channels aids in maintaining signal integrity and precise timing control, which is particularly beneficial in applications requiring synchronized switching.

With a propagation delay time of typically 15ns and a rise and fall time of typically 25ns with a 1nF load, the FAN3226CMPX ensures swift and responsive operation, minimizing transition times and reducing power dissipation during the switching cycle. Additionally, the device features a robust 4.5kV ESD (Electrostatic Discharge) protection, which enhances its durability and reliability in harsh environments.

The FAN3226CMPX is offered in a compact 8-pin SOIC package, which is suitable for space-constrained applications. Its industry-standard footprint allows for easy integration into existing designs without significant board layout changes. The driver's lead-free and RoHS-compliant construction aligns with environmental standards, ensuring suitability for eco-friendly products and markets with strict regulations.

In summary, the FAN3226CMPX from ON Semiconductor is a high-performance, dual non-inverting/inverting low-side gate driver that offers excellent driving capabilities, fast switching performance, and design versatility for a wide array of power management applications.
