Same model may have multiple batches, images only for reference.

VXO78012-500

Name: VXO78012-500
Brand: CUI Inc.
SKU: 1320590
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	VXO78012-500
Manufacturer	CUI Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 12V OR -12V 6W / Linear Regulator Replacement DC DC Converter 1 Output 12V or -12V 500mA or 150mA 15V, 8V - 36V, 24V Input
Datasheet	VXO78012-500 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Manufacturer	CUI Inc.
Packaging	Tray
Type	Linear Regulator Replacement
Number of Outputs	1
Voltage - Input (Min)	15V, 8V
Voltage - Input (Max)	36V, 24V
Voltage - Output 1	12V or -12V
Current - Output (Max)	500mA or 150mA
Power (Watts)	6 W
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	94%
Mounting	Through Hole
Case / Package	3-SIP Module
Size / Dimension	0.39" L x 0.28" W x 0.43" H (10.0mm x 7.2mm x 11.0mm)
Approval Agency	CB Scheme, EN, IEC, UL
Standard Number	55024; 55032 Class A; 60950-1
Base Product Number	VXO78012
RoHS Status	RoHS Compliant
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Other Part Number	102-4250
Standard Package	374
Win Source Part Number	1320590-VXO78012-500
Ultra Librarian 3D Model	Ultra Librarian VXO78012-500 CAD Model

Alternative Products

Description

The 1320590-VXO78012-500 DC DC Converter by CUI Inc. is a linear regulator replacement board mount component that features SCP.

Feature: SCP
Package: tray
Application: ITE (Commercial)
Standard Package: 374
Mounting Feature: through-hole
Power: 6W
Outputs: 1 output
Current Output (max): 500mA or 150mA
Voltage Input (min): 15V, 8V
Voltage Input (max): 36V, 24V
Voltage Output 1: 12V or -12V
Efficiency: 94%
Industry-Recognized Mating Diameter: 3.20mm ID, 9.00mm OD (RCA)
RoHS Compliant: Yes
Other Part Number: 102-4250
