IHLP2525CZER4R7M01 Vishay IHLP2525CZER4R7M01 Real Image1 IHLP2525CZER4R7M01 Real Image2 IHLP2525CZER4R7M01 label picture IHLP2525CZER4R7M01 label picture 2
Same model may have multiple batches, images only for reference.
IHLP2525CZER4R7M01 Vishay IHLP2525CZER4R7M01 Real Image1 IHLP2525CZER4R7M01 Real Image2 IHLP2525CZER4R7M01 label picture IHLP2525CZER4R7M01 label picture 2
IHLP2525CZER4R7M01 Vishay IHLP2525CZER4R7M01 Real Image1 IHLP2525CZER4R7M01 Real Image2 IHLP2525CZER4R7M01 label picture IHLP2525CZER4R7M01 label picture 2
Same model may have multiple batches, images only for reference.

IHLP2525CZER4R7M01

Part No IHLP2525CZER4R7M01
Manufacturer Vishay
Catalog Fixed Inductors
Description FIXED IND 4.7UH 5.5A 40 MOHM SMD
Datasheet
IHLP2525CZER4R7M01 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Molded
Inductance 4.7μH
Tolerance ±20%
Current Rating 5.5A
Current - Saturation 10A
DC Resistance (DCR) 40 mOhm Max
Temperature Range - Operating -55°C to 125°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.118" (3.00mm)
Win Source Part Number 017173-IHLP2525CZER4R7M01
Family Name IHLP-2525CZ-01
Introduction Date October 17, 2006
ECCN EAR99
Country of Origin China, Israel, United States of America
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Computers & Computer Peripherals, Communications & Networking, Portable Devices
Quantity per package 2k pcs
Ultra Librarian 3D Model Ultra Librarian IHLP2525CZER4R7M01 CAD Model

Description

The Vishay 017173-IHLP2525CZER4R7M01 is an inductor that belongs to the inductors, coils, chokes category.

  • Supply and Demand Status: currently in balance
  • Current Rating: 5.5A
  • Inductance: 4.7μH
  • DC Resistance (DCR): 40 mOhm max
  • Halogen-Free: compliant
  • Manufacturer: Vishay
