IHLP1616ABER1R0M11 Vishay IHLP1616ABER1R0M11 Real Image IHLP1616ABER1R0M11 real image IHLP1616ABER1R0M11 real image 2
Same model may have multiple batches, images only for reference.
IHLP1616ABER1R0M11 Vishay IHLP1616ABER1R0M11 Real Image IHLP1616ABER1R0M11 real image IHLP1616ABER1R0M11 real image 2
IHLP1616ABER1R0M11 Vishay IHLP1616ABER1R0M11 Real Image IHLP1616ABER1R0M11 real image IHLP1616ABER1R0M11 real image 2
Same model may have multiple batches, images only for reference.

IHLP1616ABER1R0M11

Part No IHLP1616ABER1R0M11
Manufacturer Vishay
Catalog Fixed Inductors
Description Inductor Power Shielded Wirewound 1uH 20% 100KHz Powdered Iron 4.2A 0.047Ohm DCR 1616 T/R / FIXED IND 1UH 4.2A 47 MOHM SMD
Datasheet
IHLP1616ABER1R0M11 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Molded
Inductance 1μH
Tolerance ±20%
Current Rating 4.2A
Current - Saturation 4.5A
DC Resistance (DCR) 47 mOhm Max
Frequency - Self Resonant 71MHz
Temperature Range - Operating -55°C to 125°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.047" (1.20mm)
Win Source Part Number 017145-IHLP1616ABER1R0M11
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name IHLP-1616AB-11
Introduction Date November 16, 2006
ECCN EAR99
Country of Origin China, Israel, United States of America
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian IHLP1616ABER1R0M11 CAD Model

Description

The Vishay IHLP-1616AB-11 inductor is a molded type inductor with a current rating of 4.2A and an inductance of 1μH.

  • GPTDescription: It has a height of 0.047" (1.20mm) and a DC resistance (DCR) of 47 mOhm Max. It has a tolerance of ±20% and a frequency of self-resonant @ 71MHz. It is a family of inductors, coils, and chokes that operates @ a temperature range of -55°C to 125°C. It is supplied in a reel - TR packaging and is available in alternative parts such as IHLP1616ABEB1R0M1A, A1109AS-H-1R0N, A997AS-1R0N, NPIS42LS1R0YTRF. Its estimated EOL date is 2029 and is compliant with halogen-free.
