DG508BEQ-T1-E3 Real Image DG508BEQ-T1-E3 Real Image
Same model may have multiple batches, images only for reference.
DG508BEQ-T1-E3 Real Image DG508BEQ-T1-E3 Real Image
DG508BEQ-T1-E3 Real Image DG508BEQ-T1-E3 Real Image
Same model may have multiple batches, images only for reference.

DG508BEQ-T1-E3

Part No DG508BEQ-T1-E3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description Precision 8-Channel/Dual 4-Channel CMOS Analog Multiplexers
Datasheet
DG508BEQ-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Vishay
Packaging Reel - TR
Number of Circuits 1
On-State Resistance (Maximum) 380 Ohm
Channel-to-Channel Matching (ΔRon) 10 Ohm
Operating Supply Voltage 12V
Dual Voltage Supply ±5 V ~ 20 V
Switch Time (Ton, Toff) (Maximum) 250ns, 240ns
-3db Bandwidth 250MHz
Charge Injection 2pC
Channel Capacitance (CS(off), CD(off)) 3pF, 13pF
Current - Leakage (IS(off)) (Maximum) 1nA
Crosstalk -88dB @ 1MHz
Operating Temperature Range -40°C ~ 125°C (TA)
Package 16-TSSOP (0.173", 4.40mm Width)
Manufacturer Package 16-TSSOP
Win Source Part Number 1167617-DG508BEQ-T1-E3
Manufacturer Homepage www.vishay.com
Popularity Medium
Supply and Demand Status Limited
Family Name DG508B
Introduction Date May 04, 2009
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian DG508BEQ-T1-E3 CAD Model

Description

The Vishay 1167617-DG508BEQ-T1-E3 is a 16-TSSOP (0.173", 4.40mm Width) integrated circuit with a dual voltage supply of ±5 V ~ 20 V.

  • On-State Resistance (Maximum): 380 Ohm
  • Switch Time (Ton, Toff) (Maximum): 250ns, 240ns
  • Current Leakage (IS(off)) (Maximum): 1nA
  • -3db Bandwidth: 250MHz
  • Charge Injection: 2pC
  • Crosstalk: -88dB @ 1MHz
  • Channel-to-Channel Matching (ΔRon): 10 Ohm
  • Channel Capacitance (CS(off), CD(off)): 3pF, 13pF
  • Supply and Demand Status: Limited
