DG419DY-T1-E3 Vishay DG419DY-T1-E3 Real Image DG419DY-T1-E3 real image3276 DG419DY-T1-E3 Real Image1 DG419DY-T1-E3 Real Image2 DG419DY-T1-E3 Real Image3 DG419DY-T1-E3 Real Image4
Same model may have multiple batches, images only for reference.
DG419DY-T1-E3 Vishay DG419DY-T1-E3 Real Image DG419DY-T1-E3 real image3276 DG419DY-T1-E3 Real Image1 DG419DY-T1-E3 Real Image2 DG419DY-T1-E3 Real Image3 DG419DY-T1-E3 Real Image4
DG419DY-T1-E3 Vishay DG419DY-T1-E3 Real Image DG419DY-T1-E3 real image3276 DG419DY-T1-E3 Real Image1 DG419DY-T1-E3 Real Image2 DG419DY-T1-E3 Real Image3 DG419DY-T1-E3 Real Image4
Same model may have multiple batches, images only for reference.

DG419DY-T1-E3

Part No DG419DY-T1-E3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC ANALOG SWITCH CMOS 8SOIC
Datasheet
DG419DY-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Vishay
Packaging Reel - TR
Status Active
Switch Circuit SPDT
Number of Circuits 1
Max On Resistance 35 Ohm
Single Supply Voltage (V+) 12V
Dual Supply Voltage(V±) ±15V
Max Switch Time (Ton,Toff) 175ns, 145ns
Charge Injection 60pC
Channel Capacitance(CS off, CD off) 8pF, 8pF
Max Leakage Current (IS off) 250pA
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 8-SOIC
Win Source Part Number 014279-DG419DY-T1-E3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Test & Measurement, Defence, Military & Aerospace, Power Management, Sensing & Instrumentation, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian DG419DY-T1-E3 CAD Model

Description

DG419DY-T1-E3 High-Speed Analog Switch

The DG419DY-T1-E3 offers a balance of performance and cost-efficiency for high-speed switching. It is built to handle both digital and analog signals with precision.

  • Applications: Analog to Digital Converters (ADC), Signal Multiplexers, Wireless Communication Equipment, Home Audio Systems
  • Features and Benefits: Rapid Switching Action, Seamless Signal Transition, Low Crosstalk, Robust Packaging
  • Additional Details: The DG419DY-T1-E3 supports dual-supply operation, providing flexibility in power-supply configurations tailored to specific application needs.
