The TMUX6119DCNR is a cutting-edge precision analog multiplexer from Texas Instruments, designed to provide exceptional performance in a wide range of applications. This device is part of the TMUX series, which is renowned for its high-quality signal switching capabilities.

Key Features

• Low On-Resistance: The TMUX6119DCNR boasts a low on-resistance (Ron) that typically sits around 3.5 Ω, ensuring minimal signal distortion and power loss during operation.
• Wide Operating Voltage Range: It operates across a wide voltage range of 1.08V to 5.5V, making it versatile for both single and dual supply operations.
• Single-Channel Configuration: This device offers a single-channel 1:1 configuration, allowing for precise and straightforward signal routing.
• Low Charge Injection: With low charge injection, the TMUX6119DCNR minimizes the impact on the signal integrity, which is critical for precision applications.
• Extended Temperature Range: It is designed to operate within an extended industrial temperature range of -40°C to 125°C, ensuring reliable performance under various environmental conditions.

Applications

The TMUX6119DCNR is ideal for a range of applications, including:

• Data acquisition systems
• Test and measurement equipment
• Medical equipment
• Communication systems

Quality and Reliability

Texas Instruments is committed to delivering high-quality and reliable components. The TMUX6119DCNR is no exception, as it is built to meet stringent industry standards. With Texas Instruments' reputation for excellence, users can trust this multiplexer for their critical signal switching needs.

Package and Availability

The TMUX6119DCNR comes in a compact 6-pin SOT-23 package, which is suitable for space-constrained applications. It is also RoHS compliant, adhering to environmental standards regarding hazardous substances. For availability and ordering information, customers can visit the Texas Instruments website or contact authorized distributors.
