Product Overview: CD74HC4067SM96

The CD74HC4067SM96 is a high-performance, digitally controlled analog switch fabricated by Texas Instruments, a leader in semiconductor design and manufacturing. This integrated circuit (IC) is part of the HC family and is designed to provide efficient multiplexing and demultiplexing of analog or digital signals. It is an essential component in various applications, including signal routing, data acquisition systems, and communication devices.

Key Features

• 16-Channel Multiplexer/Demultiplexer: The CD74HC4067SM96 offers 16 analog channels which can be controlled by a 4-bit binary address. This allows for a broad range of signal management possibilities within a single IC.
• Wide Operating Voltage Range: With an operational voltage range of 2V to 6V, this multiplexer is suitable for interfacing with both TTL and CMOS logic levels, providing design flexibility for a variety of systems.
• Low ON Resistance: The switch features low ON resistance, which translates to minimal signal distortion and ensures high signal integrity during the routing process.
• Low Crosstalk: Crosstalk between channels is minimized, which is critical for maintaining the purity of signal transmission, especially in sensitive audio and data applications.
• Break-before-make Switching: This functionality ensures that a new channel connection is made only after the previous connection has been broken, preventing undesirable signal mixing.

Applications

The versatility of the CD74HC4067SM96 makes it an ideal choice for a wide array of applications. It is particularly useful in:

• Analog and digital multiplexing/demultiplexing
• Signal gating
• Data acquisition systems
• Communication systems
• Audio/video switching

Package and Quality

The CD74HC4067SM96 comes in a surface-mount, lead-free package that is designed for automated assembly processes, ensuring a reliable connection to the PCB. Texas Instruments is committed to high-quality standards, and this product is no exception, meeting stringent industry requirements for performance and reliability.

Part Number: CD74HC4067SM96

Manufacturer: Texas Instruments
