ZM5304AU-CME3R Real Image ZM5304AU-CME3R real image ZM5304AU-CME3R label picture
Same model may have multiple batches, images only for reference.
ZM5304AU-CME3R Real Image ZM5304AU-CME3R real image ZM5304AU-CME3R label picture
ZM5304AU-CME3R Real Image ZM5304AU-CME3R real image ZM5304AU-CME3R label picture
Same model may have multiple batches, images only for reference.

ZM5304AU-CME3R

Part No ZM5304AU-CME3R
Manufacturer Silicon Labs
Catalog RF Transceiver Modules
Description RF TXRX MODULE ISM / FULLY INTEGRATED Z-WAVE® WIRELESS MODEM WITH ON-BOARD ANTENNA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Silicon Labs
Packaging Reel
Part Status Last Time Buy
RF Family/Standard General ISM
Protocol Z-Wave
Frequency 908MHz
Data Rate 100Kbps
Power - Output 4dBm
Sensitivity -103dBm
Serial Interfaces SPI, UART, USB
Utilized IC / Part SD3503
Supply Voltage (V) 2.3V ~ 3.6V
Current - Receiving 33mA
Current - Transmitting 36mA
Mounting Style SMD
Manufacturer Package Module
Manufacturer Pack Quantity 500
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 808285-ZM5304AU-CME3R
Ultra Librarian 3D Model Ultra Librarian ZM5304AU-CME3R CAD Model

Description

The Silicon Labs 808285-ZM5304AU-CME3R is a Z-Wave protocol-based module that operates at a frequency of 908MHz.

  • Data Rate: 100Kbps
  • Power Output: 4dBm
  • Sensitivity: -103dBm
  • Current Consumption (Receiving): 33mA
  • Current Consumption (Transmitting): 36mA
  • Serial Interfaces: SPI, UART, USB
  • Packaging: Reel
  • Popularity: Medium
  • IC/Part: SD3503
  • Family/Standard: General ISM RF
