RS2255XN

Name: RS2255XN
Brand: Runic Technology
SKU: 1370805
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	RS2255XN
Manufacturer	Runic Technology
Catalog	Interface - Analog Switches, Multiplexers, Demultiplexers
Description	IC SWITCH SP4T X 1 30OHM 10MSOP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Integrated Circuits (ICs) - Interface - Analog Switches, Multiplexers, Demultiplexers
Mfr	Runic Technology
Series	-
Package	Tape & Reel
Product Status	Active
Switch Circuit	SP4T
Number of Circuits	1
On-State Resistance (Max)	30Ohm
Channel-to-Channel Matching (ΔRon)	1Ohm (Typ)
Voltage - Supply, Single (V+)	2.5V ~ 5.5V
Voltage - Supply, Dual (V±)	-
Switch Time (Ton, Toff) (Max)	90ns (Typ), 70ns (Typ)
-3db Bandwidth	180MHz
Charge Injection	6pC
Channel Capacitance (CS(off), CD(off))	12.7pF
Current - Leakage (IS(off)) (Max)	100nA
Crosstalk	-110dB @ 1MHz
Temperature Range - Operating	-40°C ~ 125°C (TA)
Mounting Type	Surface Mount
Package / Case	10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package	10-MSOP
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	1370805-RS2255XN
Ultra Librarian 3D Model	Ultra Librarian RS2255XN CAD Model

Description

The 1176347 is an analog switch from Runic Technology.

Switch Type: SP4T
On-State Resistance: 30Ohm
Channel-to-Channel Matching: 1Ohm
Operating Temperature: -40°C to 125°C
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Mounting Type: Surface Mount
Voltage Supply Range: 2.5V to 5.5V
Switch Time Turn-On: 90ns (typ)
Switch Time Turn-Off: 70ns (typ)
-3db Bandwidth: 180MHz
Charge Injection: 6pC
Use: Interface applications
