The MC14094BDR2G from ON Semiconductor is a high-performance CMOS (Complementary Metal-Oxide Semiconductor) 8-bit serial shift register designed for use in a wide range of digital applications. This integrated circuit features a serial input (DS), a serial standard output (Q7’), eight parallel outputs (Q0 to Q7), a master reset (MR), and a clock input (CP). It is capable of interfacing directly with the SPI (Serial Peripheral Interface) of microcontrollers and is widely used for data transfer and signal processing tasks.

Key Features

• Logic Type: Serial-to-Parallel Shift Register
• Number of Circuits: 1
• Number of Bits per Circuit: 8
• Supply Voltage Range: 3 V to 18 V
• Operating Temperature Range: -55°C to +125°C
• Package / Case: SOIC-16
• Mounting Type: Surface Mount
• Output Type: Tri-State

Applications

With its versatile features, the MC14094BDR2G is suitable for a variety of applications, including:

• Serial-to-parallel data conversion
• Remote control systems
• LED displays and indicators
• Digital signal processing
• Data logging and storage systems
• Automotive systems

Quality and Reliability

ON Semiconductor is known for its commitment to quality and reliability, and the MC14094BDR2G is no exception. The device is manufactured under strict quality control standards and is designed to meet or exceed the requirements of the most demanding applications. It is also RoHS compliant, ensuring it meets the latest environmental standards for electronic components.

Conclusion

The MC14094BDR2G is a versatile and reliable component that offers a simple and effective solution for serial-to-parallel data conversion and other related functions. Whether used in consumer electronics, automotive systems, or industrial control units, this shift register from ON Semiconductor is an excellent choice for designers looking for a high-performance data processing solution.
