Products specifications

Categories Integrated Circuits
Manufacturer NXP
Packaging Bulk
Status Obsolete(EOL)
Applications CATV
Number of Circuits 1
Operating Supply Current 425mA
Case / Package SOT115J
Win Source Part Number 79430-BGD704
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BGD704 CAD Model

Description

Introducing the BGD704 from NXP Semiconductors

The BGD704 is a state-of-the-art, high-performance silicon NPN bipolar transistor crafted by the renowned NXP Semiconductors. Designed to operate at high voltages, this transistor is a perfect fit for a variety of demanding applications, including but not limited to, professional RF amplification systems.

Key Features

  • High Efficiency: The BGD704 boasts impressive efficiency, which makes it an ideal choice for applications where power economy is critical.
  • Wideband Capability: With its broadband performance, the BGD704 can handle a wide range of frequencies, ensuring versatility across different RF applications.
  • High Gain: The device offers high power gain, which allows for significant signal amplification, enhancing the overall system performance.
  • Robust Design: NXP's commitment to quality means that the BGD704 is built to withstand tough conditions, ensuring reliability and longevity.

Applications

The BGD704 is incredibly versatile and can be utilized in a multitude of RF applications. It's particularly well-suited for use in professional broadcasting equipment, cellular base station amplifiers, and RF power amplifiers in industrial, scientific, and medical (ISM) applications. Its robust design also makes it an excellent choice for use in high-voltage environments and situations where reliability is paramount.

Technical Specifications

Parameter Value Configuration Single Transistor Polarity NPN Collector-Emitter Voltage VCEO Max 28 V Emitter-Base Voltage VEBO 5 V Collector-Emitter Saturation Voltage 1 V Maximum DC Collector Current 4 A Power Dissipation 34.5 W Operating Temperature Range -65 to +150 °C

In conclusion, the BGD704 from NXP Semiconductors is a powerful and reliable component that offers a blend of efficiency, high gain, and wideband capability, making it an excellent choice for high-performance RF applications.
