Maxim Integrated's DG408DY+T Multiplexer

The DG408DY+T from Maxim Integrated is a high-performance, single 8-channel CMOS analog multiplexer that is designed to connect a single output to one of the eight inputs, depending on the state of the address inputs. This component is ideal for applications that require a reliable and efficient way to route multiple signal lines through a single channel.

Key Features

• Low On-Resistance: The DG408DY+T features a low on-resistance of 100Ω (max), which minimizes signal attenuation and ensures high signal integrity.
• Low Crosstalk: With a crosstalk between channels being significantly low, this multiplexer provides excellent isolation for complex signal routing.
• Single Supply Operation: It operates with a single power supply ranging from +10V to +30V or dual supplies of ±5V to ±20V, adding to its versatility in different circuit configurations.
• Low Power Consumption: The device has a low power consumption, which makes it suitable for battery-operated and power-sensitive applications.
• TTL/CMOS Compatible: The logic inputs are compatible with both TTL and CMOS levels, making it easy to interface with a wide range of control logic.
• ESD Protection: The DG408DY+T comes with built-in ESD protection diodes that safeguard the device from electrostatic discharges, enhancing its durability and reliability.
• Wide Operating Temperature Range: It is designed to operate over an extended temperature range from -40°C to +85°C, suitable for industrial environments.

Applications

The DG408DY+T is commonly used in various applications, such as:

• Data acquisition systems
• Audio and video switching
• Test equipment
• Communication systems
• Medical equipment

Maxim Integrated's DG408DY+T offers a combination of performance, versatility, and reliability, making it a preferred choice for designers looking to manage multiple analog signals in their electronic systems.
