GAL16V8D-7LPN Real Image GAL16V8D-7LPN real image15484
Same model may have multiple batches, images only for reference.
GAL16V8D-7LPN Real Image GAL16V8D-7LPN real image15484
GAL16V8D-7LPN Real Image GAL16V8D-7LPN real image15484
Same model may have multiple batches, images only for reference.

GAL16V8D-7LPN

Part No GAL16V8D-7LPN
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 8MC 7.5NS 20DIP
Datasheet
GAL16V8D-7LPN Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Bulk
Status Obsolete(EOL)
Programmable Type EE PLD
Delay Time tpd(1) Max 7.5ns
Voltage Supply - Internal 4.75 V to 5.25 V
Number of Macrocells 8
Temperature Range - Operating 0°C to 75°C (TA)
Mounting Through Hole
Case / Package 20-PDIP
Win Source Part Number 1040765-GAL16V8D-7LPN
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GAL16V8D-7LPN CAD Model

Description

The Lattice Semiconductor Corporation 1040765-GAL16V8D-7LPN is an EE PLD with 8 macrocells and a delay time of tpd(1) max 7.5ns.

  • Voltage Supply: 4.75 V to 5.25 V
  • Package: 20-PDIP through-hole
