IRS21864SPBF Real Image IRS21864SPBF real image10327
Same model may have multiple batches, images only for reference.
IRS21864SPBF Real Image IRS21864SPBF real image10327
IRS21864SPBF Real Image IRS21864SPBF real image10327
Same model may have multiple batches, images only for reference.

IRS21864SPBF

Part No IRS21864SPBF
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description IC DRIVER HI/LO SIDE 600V 14SOIC
Datasheet
IRS21864SPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Supply Voltage - Operating 10 V to 20 V
Logic Voltage - VIL, VIH 0.8V, 2.5V
Current - Peak Output (Source, Sink) 4A, 4A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 600V
Rise and Fall Time 22ns, 18ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 1047791-IRS21864SPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRS21864SPBF CAD Model

Description

The Infineon Technologies 1047791-IRS21864SPBF is an integrated circuit that includes two independent channels.

  • Channels: Two Independent
  • Input Type: Non-Inverting
  • Driven Configuration: Half-Bridge
  • Rise Time: 22ns
  • Fall Time: 18ns
  • Maximum High Side Voltage: 600V
  • Supply Voltage Operating Range: 10V to 20V
  • Package: 14-SOIC
  • Popularity: Medium
