IRS21271STRPBF

Name: IRS21271STRPBF
Brand: Infineon Technologies
SKU: 161795
Availability: InStock
Rating: 4.84 (132 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRS21271STRPBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	Driver 600V 1-OUT High Side/Low Side Automotive 8-Pin SOIC N T/R / IC DVR CURRENT SENSE 1CH 8-SOIC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Driven Configuration	High-Side
Channel Type	Single
Number of Drivers	1
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	9 V to 20 V
Logic Voltage - VIL, VIH	0.8V, 2.5V
Current - Peak Output (Source, Sink)	290mA, 600mA
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise and Fall Time	80ns, 40ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SOIC
Win Source Part Number	135530-IRS21271STRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRS21271
Introduction Date	October 11, 2006
ECCN	EAR99
Country of Origin	China , Thailand
Halogen Free	Compliant
Estimated EOL Date	2025
Ultra Librarian 3D Model	Ultra Librarian IRS21271STRPBF CAD Model

Description

The Infineon Technologies IRS21271STRPBF is a high-side driver IC with a single channel.

Function: drive IGBT and N-Channel MOSFET transistors in a high-side configuration
Input Type: non-inverting
Gate Type: IGBT or N-Channel MOSFET
Logic Voltage Range: 0.8V to 2.5V
Peak Output Current (Source): 290mA
Peak Output Current (Sink): 600mA
High-Side Voltage: up to 600V with bootstrap
Package: 8-SOIC
Operating Temperature Range: -40°C to 150°C
Popular Choice: driving motors and other high-power applications
