IR2110PBF

Name: IR2110PBF
Brand: Infineon Technologies
SKU: 158846
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IR2110PBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC DRIVER HIGH/LOW SIDE 14DIP
Datasheet	IR2110PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	3.3 V to 20 V
Logic Voltage - VIL, VIH	6V, 9.5V
Current - Peak Output (Source, Sink)	2A, 2A
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	500V
Rise and Fall Time	25ns, 17ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	14-DIP
Win Source Part Number	090354-IR2110PBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Motor Drive & Control
Family Name	IR2110
Introduction Date	March 26, 2004
ECCN	EAR99
Country of Origin	China, Indonesia, Thailand
Halogen Free	Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian IR2110PBF CAD Model

Description

The Infineon Technologies IR2110PBF is an integrated circuit that is designed for use in motor drive and control applications.

Channel Type: Independent
Input Type: Non-Inverting
Driven Configuration: Half-Bridge
Gate Type: IGBT, N-Channel MOSFET
Current Peak Output: 2A, 2A
High Side Voltage: 500V
Package Type: 14-DIP
Operating Temperature Range: -40°C to 150°C (TJ)
Popularity: High
