Same model may have multiple batches, images only for reference.
ESP32-C3-MINI-1U-N4 Espressif
Same model may have multiple batches, images only for reference.

ESP32-C3-MINI-1U-N4

Part No ESP32-C3-MINI-1U-N4
Manufacturer Espressif
Catalog RF Transceiver Modules
Description SMD MODULE, ESP32-C3FN4, IPEX AN / Bluetooth, WiFi 802.11b/g/n, Bluetooth v5.0 Transceiver Module 2.412GHz ~ 2.484GHz Antenna Not Included, U.FL Surface Mount
Datasheet
ESP32-C3-MINI-1U-N4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Transceiver Modules and Modems
Mfr Espressif Systems
Series ESP32-C3
Package Tape & Reel
Product Status Active
RF Family/Standard Bluetooth, WiFi
Protocol 802.11b/g/n, Bluetooth v5.0
Modulation -
Frequency 2.412GHz ~ 2.484GHz
Data Rate 150Mbps
Power - Output 20.5dBm
Sensitivity -104dBm
Serial Interfaces ADC, GPIO, I²C, I²S, JTAG, PWM, SPI, UART, USB
Antenna Type Antenna Not Included, U.FL
Utilized IC / Part ESP32-C3FN4
Memory Size 4MB Flash, 384kB ROM, 408kB SRAM
Voltage - Supply 3V ~ 3.6V
Current - Receiving 82mA ~ 84mA
Current - Transmitting 290mA ~ 350mA
Mounting Type Surface Mount
Temperature Range - Operating -40°C ~ 85°C (TA)
Package / Case 53-SMD Module
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 5A992C
HTSUS 8517.62.0090
Win Source Part Number 1353781-ESP32-C3-MINI-1U-N4
Ultra Librarian 3D Model Ultra Librarian ESP32-C3-MINI-1U-N4 CAD Model

Description

The ESP32-C3-MINI-1U-N4 is a RF transceiver module designed for wireless communication applications, manufactured by Espressif Systems.

  • Series: ESP32-C3
  • Frequency: 2.412GHz to 2.484GHz
  • Voltage Supply: 3V to 3.6V
  • Memory: 4MB Flash, 384kB ROM, 408kB SRAM
  • Protocols: Bluetooth, WiFi
  • Data Rate: 150Mbps
  • Antenna Connector: U.FL
  • Serial Interfaces: ADC, GPIO, I2C, I2S, JTAG, PWM, SPI, UART, USB
  • Power Output: 20.5dBm
  • Sensitivity: -104dBm
  • Package: 53-SMD Module
  • Mounting Type: Surface Mount
