ADG721BRMZ-REEL7

Part No ADG721BRMZ-REEL7
Manufacturer Analog Devices Inc.
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC SWITCH DUAL SPST 8MSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Reel - TR
Status Active
Switch Circuit SPST - NO
Number of Circuits 2
Max On Resistance 4 Ohm
Channel-to-Channel Matching (ΔRon) 300 mOhm
Single Supply Voltage (V+) 1.8 V to 5.5 V
Max Switch Time (Ton,Toff) 14ns, 6ns (Typ)
-3db Bandwidth 200MHz
Charge Injection 2pC
Channel Capacitance(CS off, CD off) 7pF, 7pF
Max Leakage Current (IS off) 250pA
Crosstalk -97dB @ 1MHz
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 8-MSOP
Win Source Part Number 008878-ADG721BRMZ-REEL7
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADG721BRMZ-REEL7 CAD Model

Description

Product Overview: ADG721BRMZ-REEL7

The ADG721BRMZ-REEL7 is a high-performance CMOS switch fabricated by Analog Devices Inc., a leader in semiconductor design and manufacturing. This product comes in a compact MSOP-10 package and is part of the REEL7 tape and reel packaging variant, suitable for automated assembly processes.

The ADG721 is a dual single-pole/single-throw (SPST) switch, offering excellent signal integrity with its low on-resistance and on-resistance flatness. The switch is designed for a wide range of applications, including data acquisition systems, communication systems, and relay replacements. Its versatility makes it an ideal choice for designers looking for a reliable switching solution that can handle both analog and digital signals.

Key Features:

  • Low On-Resistance: Typically just 0.4 ohms, this switch provides minimal signal distortion and ensures high efficiency in signal routing.
  • Single Supply Operation: Operating from a single 1.8V to 5.5V supply, the ADG721BRMZ-REEL7 is compatible with a variety of logic families and simplifies power supply design.
  • Fast Switching: With transition times in the nanosecond range, this device can handle high-speed signals without significant latency.
  • Low Power Consumption: The ultra-low power consumption makes it suitable for battery-powered portable devices, helping to extend battery life.
  • Bidirectional Signal Flow: Signals can flow in both directions through the switch, offering design flexibility.

Applications:

  • Test Equipment
  • Audio and Video Switching
  • Data Acquisition Systems
  • Sample Hold Systems
  • Communication Systems

The ADG721BRMZ-REEL7 is a testament to Analog Devices' commitment to providing high-quality, high-performance integrated circuits. With its robust feature set and flexible operation, this switch is a smart choice for engineers and designers looking to enhance their electronic designs with reliable and efficient signal routing capabilities.
