ABM3-16.000MHZ-D2Y-T Real Image ABM3-16.000MHZ-D2Y-T real image24140
Same model may have multiple batches, images only for reference.
ABM3-16.000MHZ-D2Y-T Real Image ABM3-16.000MHZ-D2Y-T real image24140
ABM3-16.000MHZ-D2Y-T Real Image ABM3-16.000MHZ-D2Y-T real image24140
Same model may have multiple batches, images only for reference.

ABM3-16.000MHZ-D2Y-T

Part No ABM3-16.000MHZ-D2Y-T
Manufacturer Abracon LLC
Catalog Oscillators
Description CRYSTAL 16.0000MHZ 18PF SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Crystals
Mfr Abracon LLC
Series ABM3
Package Tape & Reel
Product Status Active
Type MHz Crystal
Frequency 16 MHz
Frequency Stability ±30ppm
Frequency Tolerance ±20ppm
Load Capacitance 18pF
ESR (Equivalent Series Resistance) 40 Ohms
Operating Mode Fundamental
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 2-SMD, No Lead
Size / Dimension 0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max) 0.051" (1.30mm)
Standard Package 1,000 pcs
MSL Level Not Applicable
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.60.0050
Win Source Part Number 851259-ABM3-16.000MHZ-D2Y-T
Ultra Librarian 3D Model Ultra Librarian ABM3-16.000MHZ-D2Y-T CAD Model

Description

The Abracon LLC ABM3 Series MHz Crystal is a high-performance crystal oscillator that offers excellent frequency stability and accuracy.

  • Packaging: Tape and Reel
  • Standard Package: 1,000 pcs
  • Frequency: 16 MHz
  • ESR: 40 Ohms
  • Mode: Fundamental
  • Mounting Type: Surface Mount
  • Product Status: Active
  • REACH Affected: Yes
  • Manufacturer: Abracon LLC
